The first recreational catamaran
100% electric and 100% renewable energy

Solar Energy

Maximum Power 15 kWp

2 retractable and
automated wings

Hydrogeneration

3 to 10 kWp depending on vessel speed

A new conception of yachting combining performance, energy efficiency and sustainability

We have imagined a journey powered by clean, renewable energies, eliminating dependence on fossil fuels. It’s a virtuous voyage, effectively leaving no footprint on the living world.

The result of this vision is the MODX 70, a revolutionary 70-foot catamaran. The first of its kind, combining wind propulsion with the Aeroforce wings, electric propulsion and hydrogeneration, as well as solar power through 70m2 of solar panels for sustainable and unlimited sailing. Thanks to these innovations, the MODX 70 offers a sailing experience at zero CO2 emissions.

Target Speed

Wind (knots)

10

15

20

Max Speed (knots)

10

14

18

Autonomy

Engine

110 miles at 5 knots

Wing

Unlimited

Powered by innovation

Centralized, automated
& connected dashboard

Zero carbon emissions

126 tons of CO2 avoided per year,
equivalent to 60 cars
traveling 15,000 km in a year!

Specifications
Metric
Imperial
Overall length
21,33 m
70 ft
Beam
10 m
32,11 ft
Draft
2 m
6,56 ft
Air draft
4,60 m
13,12 ft
Mast clearance
23 m
75,46 ft
Wing area
2 x 125 m2
2 x 410 ft2
Light displacement
30 T
66 138 lbs
Maximum displacement load
34 T
74 956 lbs
Water recovery capacity
2 x 400 L
2 x 105,7 gal
Water storage capacity
1 200 L
264 gal
Solar panel area
70 m2 (15 kWc)
230 ft2 (15 kWc)
Battery bank
250 kW.h
Electric motor
2 x (2 x 20 kW)
Highfield 3.40 tender (6 people): L 3.4 m / Torqeedo 10 kW electric motor / 2h autonomy
Naval architects: VPLP Design
Interior design: Ocean Development
CE Certification: A (12 pax.) / B (16 pax.) / C-D (35 pax.)
Number of berths: 8/10 passengers + 2/3 crew
